Ibanez bass guitar SR505E-TVB

The Ibanez SR505E-TVB 5-String Bass Guitar is a premium 5-string bass from Ibanez's SR (Soundgear) series. The TVB finish stands for TV Fuzz Black, a limited finish introduced for certain markets.

Key Specifications

• Strings: 5
• Scale Length: 34" (864 mm)
• Body: Okoume
• Neck: SR5 5-piece Jatoba/Walnut
• Fingerboard: Rosewood (2021 onward) with Abalone oval inlays
• Frets: 24 Medium
• Nut Width: 45 mm
• Fingerboard Radius: 305 mm (12")
• Bridge: Accu-cast B505 (16.5 mm string spacing)
• Hardware: Black

Electronics

• Pickups: Bartolini BH2 passive humbuckers (neck & bridge)
• Preamp: Ibanez Custom Electronics 3-band active EQ
• Controls:
  • Master Volume
  • Pickup Balance
  • Bass
  • Mid
  • Treble
  • EQ Bypass switch (active/passive)
  • 3-way Mid Frequency selector

When the EQ is bypassed, the treble control functions as a passive tone control.

Factory Strings & Tuning

• D'Addario EXL165 + .130
• Gauges: .045 / .065 / .085 / .105 / .130
• Standard tuning: B-E-A-D-G

Finish

• TV Fuzz Black (TVB) – a distinctive textured black finish introduced in 2021 for selected markets.

Weight

Typical weight is around 3.7–4.1 kg (8.2–9.0 lb), though it varies slightly between individual instruments.

Pros

• Slim, fast-playing SR neck
• Excellent balance and comfortable ergonomics
• Versatile Bartolini BH2 pickups
• Active/passive operation for added flexibility
• Strong value for gigging, studio work, and modern styles

Considerations

• The 16.5 mm string spacing is narrower than many traditional 5-string basses, which some slap players may need time to adjust to.
• Bartolini BH2 pickups have a clean, modern voice that may not suit players seeking a vintage-style tone. Community feedback is generally positive regarding playability and overall value.
